Product Description
Common Name: Dry-Type Transformer Resin Insulation Support pad
Material: SMC, BMC
Dimensions: Various
Colors: Various
Application: For use on epoxy drums in dry-type transformers! Features high strength, excellent insulation, and superior mechanical properties. Production Range: 30kV/10kVA – 20,000kV/35kVA. Suitable for insulating spacers for dry-type transformers with a maximum capacity of 110kVA.
Product Description
Our
dry type transformer mold
is specially designed for the manufacturing of
cast resin dry type transformer coils
. It is widely used in transformer production lines for accurate coil forming and epoxy resin casting.
The mold is manufactured with high precision to ensure excellent dimensional consistency, smooth demolding, and reliable performance during repeated production cycles. According to customer requirements, we can provide
customized mold solutions
based on drawings…
The 15kV / 200A single pass bushing joint is mainly used for the high-voltage electrical connection of American box transformer and outdoor ring network cabinet. The advanced design inside the single pass pipe ensures that the arc can be extinguished normally when it is disconnected from the elbow joint.
order number
Cable cross-sectional area/mm²
Conductor diameter/mm
Cable insulation outer diameter/mm
NRDT-15/200-35
35
7.0-7.5
17.0-19.0
NRDT-15/200-50
50
8.0-8.5
18.0-20.0
NRDT-15/200-70
70
9…
15kV/200A double elbow lightning arrester is widely used in American box transformer and branch box, buried transformer, switchgear and other equipment. The product increases more space for box transformer, and has the characteristics of simple operation and compact structure.
product structure：
Insulation
Arc suppression chamber
Outer semiconducting layer
Arrester core
Copper bottom cover
Ground wire
order number
Cable cross-sectional area/mm²
Conductor diameter/mm
Cable insulation outer diamet…
This cutting machine adopts all-steel welded structure, simple structure, easy operation, beautiful appearance, low energy consumption, suitable for processing and cutting in metallurgy, light industry, machinery, transformer and other industries. The high alloy tool knife has a durable blade.
Shearable plate thickness
Shearable plate width
Shearing angle (°)
Number of strokes
Motor power
Dimensions
Weight
2
1300
2°-14°
30
4
1670*690*980
449
1.5
1600
2°-14°
30
4
1970*690*980
496
2
2000
2°-14°
30…
Electrical Aluminum foil(copper foil)shielding insulating paper is a new type of shielding insulating materia a made of high density insulation paper and high purity aluminum foil(copper foil)by special bonding process.Mainly used for transformers、mutual inductor and the ground screen、electrostatic shielding layer and coil conductive layer of reactor.It can improve the electromagnetic field distribution,reduce partial discharge、strengthen insulation、reduce loss、and improve its safety and reliabi…
We produce electrical composite coaming board by multilayer composite of polyester film and non-woven fabric,special heat resistant adhesive as the bonding material.And then surface treatment with special resin.The product has very high mechanical and electrical properties.The shrinkage and humidity absorption is low.And the thermal endurance property is very reliable.Electrical composite coaming board is mainly used for the winding of the low voltage coils in dry-typetransformers.It can replace…
