NMN(6640) flexible composite of PET film and Nomex paper

NMN(6640)is made of two layers of Nomex paper and one layer of PET film,coated with grade H thermal upgraded adhesive.It has high mechanical properties, dielectric and thermal upgrade properties, and low dissipation factor.It can be used as turn and backing insulating material in grade F and grade H transformers,motors and other electrical appliances. The NMN can work for a long time in a 180?? environment.
Recommended width
910mmand narrower.Tailor-made width is available.
Storage
The product sh…

Category: Insulation Material

SKU: N6FCO-296

Description
Additional information

Description

Recommended width

910mmand narrower.Tailor-made width is available.

Storage

The product should be stored in dry,clean and well-ventilated warehouse under 30??. The fire,heat sources and direct sunshine should be avoided.

No.	Property		Unit	Requirements
1?	Nominal thickness		mm	0.15?	0.17???? 0.20??? 0.25???? 0.30				0.37??? 0.47???? 0.52
2?	Thickness tolerance		%	??15					??10
3?	Nomex paper		mm	? 0.05?							0.08?
4?	Film nominal thickness		mm	0.05?	0.075?	0.10?	0.125?	0.188?	0.25?	0.35?	0.35?
5?	Tensile strength	MD	N/10mm Width	??150	??160	??170	??220	??270	??330	??400	??450
		CD		??90	??90	??105	??150	??200	??300	??300	??300
6?	Elongation	MD	%	??15			??20
		CD		??20				??25
7?	Breakdown Voltage	No bending	kV	??7	??8	??11	??14	??19	??23???? ??28		??30
		Bended		??6	??7	??9	??12	??15	??18	??20	һ
8?	Bonding strength	Normal	һ	No delamination
		180??2??/10min		No delamination,no bubble,no lesk of glue
Note:The specification can be determined with customers.
