Electrical composite polyester film

Electrical composite polyester film is composite polyester film is mainly used as the insulator between high-low voltage coils in the dry type transformers, and can also be used as turn or backing insulating in the motor or other high voltage electrical equipment.
Tecommended width:
1000mm??1200mm??1400mm??1500mm,Tailor-made width is available.
Storage
The product should be stored in dry,clean and well-ventilated warehouse under 30??.The fire,heat sources and direct sunshine should be avoided.
No.
P…

Category: Insulation Material

SKU: ECPF-294

Description
Additional information

Description

Tecommended width:

1000mm??1200mm??1400mm??1500mm,Tailor-made width is available.

Storage

The product should be stored in dry,clean and well-ventilated warehouse under 30??.The fire,heat sources and direct sunshine should be avoided.

No.	Property		Unit	Requirements
1?	Nominal thickness		mm	0.5?	0.9?		1.1?
2?	Tolerance of thickness		mm	??0.045	??0.09		??0.11
3?	Quantify and tolerance		g/m2	700??85	1300??130		1500??180
4?	Film thickness		Hm	250?	188?	350?	350?
5?	Tensile strength	MD	N/10mm Width	??350		??600
		CD		??350		??600
6?	Elongation	MD	%	??30		??50
		CD		??30		??50
7?	Breakdown voltage		kV	??25		??30

Read more

Electrical Semiconductor creped insulation paper

Electrical crepe paper tube is made of electrical insulation crepe paper.It’s used as insulating wrapping of naked wires in the oil immersed transformers.It has reliable flexibility.
Notes:
made by customers’requirements is available.
Storage??
The product should be stored in dry,clean and well-ventilated warehouse.The fire,heat sources and direct sunshine should be avoided.
No.
Name
Specification
Specification
1
Electrical crepe paper tube
??4mm*??8mm
1000mm
2
Electrical crepe paper tube
??6mm*??8mm…
Read more

Electrical Semiconductor creped insulation paper

Electrical Semiconductor creped insulation paper is a new kind of special shielding material.Mainly used for high voltage transformer,new energy transformer lead wrapping,interlayer insulation foil winding,ultra high voltage power cable,high voltage electrical equipment lead and coil insulation wrapping.It can replace metallized paper and other surface type semiconductor materials.It has excellent wettability,lowconductivity,shielding static electricity,also can solving partial discharge and bal…
Read more

Custom Wet Process Transformer Insulation Molded Parts for Coil and Winding Support

Wet Process Molded Insulation Parts for Transformers
are specially designed for oil-immersed power transformers and distribution transformers. They are manufactured from high-quality electrical insulation pressboard through wet molding, drying, pressing and precision processing.
These molded insulation components have excellent electrical insulation performance, high mechanical strength and good dimensional stability. They are widely used inside transformer active parts for winding support, coil…
Read more

Oil-Resistant and High-Temperature Resistant PTFE Gaskets

Product Introduction:
PTFE gaskets improved performance over conventional PTFE, Reduced product loss and emissions.Excellent bolt torque retention, unique manufacturing process minimizes cold flow problems typical of skived and expanded PTFE Sheets. It has excellent resistance to most mineral and organic chemicals? such as acids, bases, and solvents, and can be used up to approximately 260??C.
Features:
Good for use with petrol & oils
Good ozone resistance
Good for use with acids and alkalis
Good…
