Electrical SDP diamond insulation paper tape

The base paper of this product is a high-strength insulating paper made of Finland’s unique insulating pulp with high softness and toughness through super calender process.,and diamond coated with special modified epoxy resin on the surface,then cured by phase B.It is mainly used for trapezoidal insulation of oil-immersed transformer high voltage coil wound by high speed automatic winding machine.
First of all,to cure under temperature 90???5
??
for 3 hours,and then rise temperature to 125???5
??
an…

Category: Insulation Material

SKU: ESDIP-300

Description
Additional information

Description

First of all,to cure under temperature 90???5???for 3 hours,and then rise temperature to 125???5???and keep 6 hours to cure.

Storage

The product should be stored in dry,clean and well-ventilated warehouse.The fire,heat sources and direct sunshine should be avoided.The storage period is one year,qualified products exceeding the storage period can still be used.

No.	Property		Unit	Requirements
1?	Base material thickness and tolerance		mm	0.05??0.003	0.06??0.003	0.08??0.005
2?	Base material tightness		? g/cm3	0.85~1.10
3?	Thickness of single side adhesive		??m	5~15
4?	Moisture		%	4.0~8.0
5?	Ash		%	??1.0
6?	Conductivity of water extract		mS/m	??10
7?	PH value of water extract		һ	6.5~8.5
8?	0il absorbency		%	??20
9?	Bonding strength	Normal	k	??800
		100???2??		??600
10?	Contamination of transformer oil		һ	No pollution(??tan??<0.001)
11?	Tensile strength	MD	N/15mm Width	??65	??75	??100
		CD		??25	??35	??45
12?	Tear strength	MD	mN	??400	??450	??800
		CD		??550	??650	??1000
13?	Breakdown Voltage	In air	kV	??0.50	??0.60	??0.88
		In oil		??3.00	??3.50	??4.40

Read more

Oil duct strip and Other Insulation molding parts of 35KV and below

Oil duct strip is composed of rectangular strip and diamond dotted insulation paper,it’s widely used in oilimmersed transformer.The product can avoid the weaknesses of easy deformation,easy to produce displacement and others.It can combine with the coil very well,has better mechanical and electrical properties.
Insulation molding parts include end ring, a pressing ring, the whole insulation tube stay, angle ring, lead angle ring piece, overall angle ring and series products. They are produced by…
Read more

Electrical Heat-resistant Diamond Dotted Insulating Paper(Thermal DDP)

The base paper of thermal DDP is the highly polymerized(DP value)cellulose paper produced from the nitrogenous Finland insulating wood pulp,and diamond coated with special modified epoxy resin on the surface,then cured by phase B.So the thermal DDP has good heat stability,mechanical and electrical properties.It is mainly used for natural ester new energy such as high ignition point vegetable oil and high overload oil-immersed transformers.
Product Solidification Conditions
Read more

NMN(6640) flexible composite of PET film and Nomex paper

NMN(6640)is made of two layers of Nomex paper and one layer of PET film,coated with grade H thermal upgraded adhesive.It has high mechanical properties, dielectric and thermal upgrade properties, and low dissipation factor.It can be used as turn and backing insulating material in grade F and grade H transformers,motors and other electrical appliances. The NMN can work for a long time in a 180?? environment.
Recommended width
910mmand narrower.Tailor-made width is available.
Storage
The product sh…
Read more

Electrical Semiconductor creped insulation paper

Electrical crepe paper tube is made of electrical insulation crepe paper.It’s used as insulating wrapping of naked wires in the oil immersed transformers.It has reliable flexibility.
Notes:
made by customers’requirements is available.
Storage??
The product should be stored in dry,clean and well-ventilated warehouse.The fire,heat sources and direct sunshine should be avoided.
No.
Name
Specification
Specification
1
Electrical crepe paper tube
??4mm*??8mm
1000mm
2
Electrical crepe paper tube
??6mm*??8mm…
