Electrical Semiconductor creped insulation paper

Electrical crepe paper tube is made of electrical insulation crepe paper.It’s used as insulating wrapping of naked wires in the oil immersed transformers.It has reliable flexibility.
Notes:
made by customers’requirements is available.
Storage??
The product should be stored in dry,clean and well-ventilated warehouse.The fire,heat sources and direct sunshine should be avoided.
No.
Name
Specification
Specification
1
Electrical crepe paper tube
??4mm*??8mm
1000mm
2
Electrical crepe paper tube
??6mm*??8mm…

Category: Insulation Material

SKU: ESCIP-299

Description
Additional information

Description

Electrical crepe paper tube is made of electrical insulation crepe paper.It’s used as insulating wrapping of naked wires in the oil immersed transformers.It has reliable flexibility.

Notes:

made by customers’requirements is available.

Storage??

The product should be stored in dry,clean and well-ventilated warehouse.The fire,heat sources and direct sunshine should be avoided.

No.	Name	Specification	Specification
1?	Electrical crepe paper tube	??4mm*??8mm	1000mm
2?	Electrical crepe paper tube	??6mm*??8mm	1000mm
3?	Electrical crepe paper tube	??6mm*??9mm	1000mm
4?	Electrical crepe paper tube	??8mm*??10mm	1000mm
5?	Electrical crepe paper tube	??8mm*??14mm	1000mm
6?	Electrical crepe paper tube	??9mm*??12mm	1000mm
7?	Electrical crepe paper tube	??10mm*??12mm	1000m
8?	Electrical crepe paper tube	??12mm*??16mm	1000mm
9?	Electrical crepe paper tube	??12mm*??20mm	1000mm
10?	Electrical crepe paper tube	??14mm*??16mm	1000m
11?	Electrical crepe paper tube	??14mm*??17mm	1000mm
12?	Electrical crepe paper tube	??16mm*??20mm	1000mm
13?	Electrical crepe paper tube	??18mm*??21mm	1000mm
14?	Electrical crepe paper tube	??18mm*??26mm	1000mm
15?	Electrical crepe paper tube	??20mm*??25mm	1000mm
16?	Electrical crepe paper tube	??34mm*??38mm	1000mm
17?	Electrical crepe paper tube	??46mm*??50mm	1000mm
18?	Electrical crepe paper tube	??68mm*??72mm	1000mm
