Description
A silicon steel strip slitting line is a production and processing equipment that slits coiled silicon steel strip into strips of a specific width and then winds them into coils at a specific winding tension. It is widely used in metal sheet processing industries such as food, packaging, building materials, and electrical engineering.
Production Line Equipment Components:
1) Electric loading trolley;
2) Hydraulically expanding and retracting unwinder;
3) Buffer pit guide;
4) Material receiving device;
5) Movable guide device;
6) Slitting machine;
7) Material receiving bridge;
8) Tensioning device;
9) Hydraulically expanding and retracting winder;
10) Electric unloading trolley;
11) Hydraulic station and pneumatic system;
12) Electrical control cabinet and operating console;
| Inner diameter of coil | Ø500mm |
| Width of coil | 200-1200mm |
| Weight of coil | 5T |
| Thickness of sheet | 0.23-0.5mm |
| Width of sheet | 40-1200mm |
| Shearing speed | 0~120m/min |
| Straightness deviation of each edge | 0.1mm/m |
| Strip with accuracy | ±0.1mm |
| Installed power | 55KW |
