This product is to coat the modified epoxy resin on insulating PMP foils in diamond shape.The material is mainly used for insulation between coils of medium and low voltage transformer lines,at the mold temperature 90??,the foil can be bonded with the wire in 2 seconds;During winding process,the foil will protect the wired form any displacement,with the premises to guarantee the coils’electrical properties and the mechanical properties.This environmental friendly product will increase the yield a…
Electrical crepe paper tube is made of electrical insulation crepe paper.It’s used as insulating wrapping of naked wires in the oil immersed transformers.It has reliable flexibility.
Notes:
made by customers’requirements is available.
Storage??
The product should be stored in dry,clean and well-ventilated warehouse.The fire,heat sources and direct sunshine should be avoided.
No.
Name
Specification
Specification
1
Electrical crepe paper tube
??4mm*??8mm
1000mm
2
Electrical crepe paper tube
??6mm*??8mm…
Electrical Semiconductor creped insulation paper is a new kind of special shielding material.Mainly used for high voltage transformer,new energy transformer lead wrapping,interlayer insulation foil winding,ultra high voltage power cable,high voltage electrical equipment lead and coil insulation wrapping.It can replace metallized paper and other surface type semiconductor materials.It has excellent wettability,lowconductivity,shielding static electricity,also can solving partial discharge and bal…
Diamond dotted insulation paper(DDP)is made by coating special modified epoxy resin on the high-performance and low dielectric loss insulating paper.It is widely applied in inter-layer insulation and turn insulation of oil-immersed power transformers.It is able to prevent the displacement of coillayers after winding and curing,so as to ensure the steady mechanical and electrical performance of insulation structure.
No.
Property
Unit
Requirements
1
Base material thickness and tolerance
mm
0.08??0….
