High Precision 30T Vertical Winding Machine for Power Transformer Coil
High Precision 30T Vertical Winding Machine for Power Transformer Coil - 图片 2
High Precision 30T Vertical Winding Machine for Power Transformer Coil - 图片 3
High Precision 30T Vertical Winding Machine for Power Transformer Coil - 图片 4
High Precision 30T Vertical Winding Machine for Power Transformer Coil - 图片 5

High Precision 30T Vertical Winding Machine for Power Transformer Coil

1.This machine is chuck elevation type (pit type), and the height of the winding coil can be arbitrarily adjusted according to the needs of the coil, the position of the operating platform is not changed, and
the operation is simple and convenient.
2.This machine is VF control speed, the speed start is smooth and the braking is reliable. The number of windings can be freely set, with a positive and reverse count and the power-off memory function. The pit cover can be freely expanded or shrunken …

Category:
SKU: HP3VW-131

Description

1.This machine is chuck elevation type (pit type), and the height of the winding coil can be arbitrarily adjusted according to the needs of the coil, the position of the operating platform is not changed, and
the operation is simple and convenient.

2.This machine is VF control speed, the speed start is smooth and the braking is reliable. The number of windings can be freely set, with a positive and reverse count and the power-off memory function. The pit cover can be freely expanded or shrunken according to the diameter of the coil, it is safe and reliable.
Model  JN-2002/3002/5002/  JN-2002/3002/5002-B  JN-1000/1300/1500 JN-300/400/500/800-Z
Shear length 1mm-99999mm 1mm-99999mm 10mm-5000mm 200-5000mm
Shear width – – 20mm-1300mm –
Shear thickness – – 0.8-4.0mm –
Shearing accuracy  + 0.02mm  + 0.02mm  + 0.3mm +0.2mm
Basic composition 20t parameters
Maximum load of the flower pan 20t
Flower disk diameter (2000mm)
T-slot Eight grooves, 28 mm wide
Maximum space diameter of rotation 3000mm
Movement cover plate extension speed 1m/min
Height of guy wire device 1000mm
Maximum clamping force of the wire 200-4000N; 30000N;
Compressed air source 0.5-0.7MPa
Maximum torque of the flower head 20000N/m
Noise at the operating position Less than 75db
Flower disk rotation system (stepless speed control) 0-10 RPM
Flower pan lifting stroke More than 3000mm, the flower disk rises to the top, the flower disk is more than 350mm above the ground, both sides are limited;
Rate of ascent 0.5m/min
service platform The opening range is 1000-3050mm; the
